Acrylic PTFE Packing

It is made from Synthetic Composite yarn and impregnated with PTFE emulsion (No lubricants or oils) to provide extra chemical resistance.This type of gland packing is a general purpose packing which can be used as a replacement of asbestos packing.It is widely used in application of alkalies, Mild acids, Solvents, Steam and oils.It is recommended for rotary shafts, Reciprocating applications and valves.It can withstand continuous temperatures up to 300c. The sizes available range from 3mm to 25mm.

Acrylic yarn impregnated with PTFE and lubricant — no oils needed
Rated to around 250°C across pH 3–12
Clean, low-friction seal at a lower cost than pure PTFE
Suited to rotary, reciprocating and valve applications
Supplied as a continuous coil, 3 mm to 25 mm cross-section

Request a Quote WhatsApp

Download Datasheet (PDF)

Overview

Acrylic PTFE Packing braids acrylic yarn impregnated with PTFE and lubricant, giving a clean, low-friction, economical seal with good chemical resistance. It is a versatile general-service packing for water and mild chemical duty.

It works to around 250°C across pH 3–12 at moderate shaft speeds, making it a cost-effective alternative to pure PTFE on non-critical pumps and valves.

Specifications

Material	Acrylic yarn, PTFE-impregnated
Max Temperature	250°C
pH Range	3 – 12
Max Shaft Speed	12 m/s
Cross-sections	3 mm to 25 mm square
Form	Continuous coil, cut to length

Applications

General water & pump service

Mild-chemical valve stems

Dilute acids & alkalis

Utility & process pumps

Low-friction clean seal

Industries Served

Commonly specified across:

Chemical Plants Textile Mills Water Treatment Sugar Mills Paper Mills

Frequently Asked Questions

What is Acrylic PTFE Packing used for?

It is a versatile, economical packing for water and mild-chemical pumps and valves where a clean, low-friction seal is needed.

What temperature suits Acrylic PTFE Packing?

It is rated to around 250°C across pH 3–12.

How does it compare to pure PTFE packing?

It offers similar cleanliness and low friction at lower cost, but pure PTFE is preferred for aggressive chemicals or food contact.

Download the Acrylic PTFE Packing Datasheet

Full specifications, applications and industries served — in one PDF for your records or to share with your team.

Download PDF

Need a quote or a spec check?

Send us your operating conditions and we'll help you source the right Acrylic PTFE Packing for the job.
